| MODEL SPEC | UNIT | TAC-10CPA/HNG |
|---|---|---|
| Cooling | (Btu/h) | 10000 |
| Cooling | (W) | 2930 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 1195 |
| Operating Current | (A) | 5.3 |
| PERFORMANCE | ||
| EER | (W/W) | 2.45 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 300 |
| Noise Level | dB(A) | 53 |
| Timer | (hrs) | 24 |
| Recommended Rm Size | (Sqm) | 12-20 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 415 X 690 X 315 |
| Net Weight | kg | 26 |
| MODEL SPEC | UNIT | TAC-12CPA/KNG |
|---|---|---|
| Cooling | (Btu/h) | 12000 |
| Cooling | (W) | 3350 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 1200 |
| Operating Current | (A) | 5.4 |
| PERFORMANCE | ||
| EER | (W/W) | 2.79 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 330 |
| Noise Level | dB(A) | 53 |
| Timer | (hrs) | 12 |
| Recommended Rm Size | (Sqm) | 14-25 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 440 x 715 x 355 |
| Net Weight | kg | 30 |
| MODEL SPEC | UNIT | TAC-14CPA/KNG |
|---|---|---|
| Cooling | (Btu/h) | 14000 |
| Cooling | (W) | 4100 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 1600 |
| Operating Current | (A) | 7.3 |
| PERFORMANCE | ||
| EER | (W/W) | 2.56 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 340 |
| Noise Level | dB(A) | 54 |
| Timer | (hrs) | 12 |
| Recommended Rm Size | (Sqm) | 16-26 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 440 x 715 x 355 |
| Net Weight | kg | 31 |
| MODEL SPEC | UNIT | TAC-18CPA/DMG |
|---|---|---|
| Cooling | (Btu/h) | 18000 |
| Cooling | (W) | 5300 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 2290 |
| Operating Current | (A) | 9.8 |
| PERFORMANCE | ||
| EER | (W/W) | 2.31 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 450 |
| Noise Level | dB(A) | 58 |
| Timer | (hrs) | 24 |
| Recommended Rm Size | (Sqm) | 22-35 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 365 x 775 x 568 |
| Net Weight | kg | 42 |
| MODEL SPEC | UNIT | TAC-18CPA/DG |
|---|---|---|
| Cooling | (Btu/h) | 18000 |
| Cooling | (W) | 5300 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 2290 |
| Operating Current | (A) | 9.8 |
| PERFORMANCE | ||
| EER | (W/W) | 2.31 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 400 |
| Noise Level | dB(A) | 58 |
| Timer | (hrs) | 24 |
| Recommended Rm Size | (Sqm) | 22-35 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 365 x 775 x 568 |
| Net Weight | kg | 45 |
| MODEL SPEC | UNIT | TAC-18CPA/DMG |
|---|---|---|
| Cooling | (Btu/h) | 20000 |
| Cooling | (W) | 5800 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 2180 |
| Operating Current | (A) | 9.8 |
| PERFORMANCE | ||
| EER | (W/W) | 2.66 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 450 |
| Noise Level | dB(A) | 58 |
| Timer | (hrs) | 24 |
| Recommended Rm Size | (Sqm) | 22-38 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 365 x 775 x 568 |
| Net Weight | kg | 47 |
| MODEL SPEC | UNIT | TAC-20CPA/DG |
|---|---|---|
| Cooling | (Btu/h) | 20000 |
| Cooling | (W) | 5800 |
| ELECTRIC DATA | ||
| Voltage, Frequency, Phase | (V,Hz,Ph) | 220-240, 50.1 |
| Input Power | (W) | 2300 |
| Operating Current | (A) | 9.8 |
| PERFORMANCE | ||
| EER | (W/W) | 2.52 |
| Refrigerant | (W/W) | R410A |
| Air Flow Volume | (m³/h) | 450 |
| Noise Level | dB(A) | 58 |
| Timer | (hrs) | 24 |
| Recommended Rm Size | (Sqm) | 24-38 |
| NET DIMENSION & WEIGHT | ||
| Net Dimension | (W.H.D)mm | 365 x 775 x 568 |
| Net Weight | kg | 45 |
